By Keith MacCauley
Among the more unfamiliar
designs of covered hopper cars (AAR designated ‘LO’) were a series built by Procor
beginning in 1969. Most likely inspired by the so called ‘Barrel’ Ore cars
constructed by NSC in 1967, the small 2,100 cu. ft. capacity cars, would spend
their entire lives in relative obscurity moving limestone minerals two hundred
miles from a mine in Cadomin (SE of Hinton, AB) to a cement processing plant
located in NW Edmonton (CN Bissell Yard). Similar to the NSC built ore cars,
they operated in unit train fashion. Constructed by Procor at their Oakville
Ontario plant between 1969 and 1980, the cars were lifetime leased to Inland
Cement.
While comparable in appearance
to the NSC built cars, the Inland LO’s featured in motion loading and unloading.
Copying the NSC roof geometry the Inland cars were equipped with full length
rectangular hatches fitted with rubber-tired masts. Scroll assemblies located
pre-loading and post loading opened and closed the hatches as the cars moved
through the filling operation. Track beneath the loading tipple was on a 2.5%
grade. Disconnected from the motive power, the cars moved through the tipple by
gravity. Connected to plant air, the cars were advanced manually and positioned
using their onboard air brakes. At the destination cement plant, unloading was
accomplished by indexing each car over a pit. Horizontal sprockets equipped
with cams and levers connected by a chain loop operated full length bottom
doors. Placed beneath the center sill the sprocket cams were engaged by angle
iron fixtures placed between the rails to open and close the doors. The bottom
doors were positioned such that the limestone payload, known as ‘rock
limestone’, was dumped outside the rails through grating into a pit.
Initial estimates of the available
limestone reserve were that the mine would play out in just over half a
century. While this would indicate a ceasing of operations in the early 2020’s,
Google earth images show current ongoing activity. Between 1969 and 1980 Procor
constructed some 181 so called ‘rock limestone’ cars. Owing to revised bridge
loading requirements (known as Cooper E60), cars built post 1976 were made
artificially longer while maintaining the same overall capacity. Related to
mayhem during unit train operation, a handful of the later built cars were constructed
as wreck replacements. The line from Cadomin to Edmonton has portions with
severe grades. As a result, Canadian National stipulated that the cars be
equipped with a higher braking ratio, i.e. higher braking forces. Nevertheless,
on one occasion the unit train ran away uncontrolled and derailed with a
handful of cars careening deep into a canyon. In the aftermath some of the
derailed cars were repaired and returned to service, while others are, in
theory, still in the canyon. At its peak, operation of the unit trains (CN
U894/895) involved sixty-car consists, scheduled twice per week. Some four
hundred thousand tons of limestone were transported annually.
Initially constructed
with UTCX reporting marks, early on the Procor rock limestone cars were
remarked UNPX. In the mid to late 1990’s, acknowledging a revised lease
structure with Lehigh Hanson, the cars were remarked with PWCX reporting marks.
Through mergers and acquisitions, Inland Cement became Lehigh Hanson and today
is known as Heidelberg Materials; see https://www.heidelbergmaterials.us/about/history. Simultaneously, in
the mid 1990’s the AAR Gross Rail Load (GRL) limit increased from 263,000 lbs
to 286,000 lbs. Owing to the forty-year eligible life limit of the initial
build of cars (built pre-July 1, 1974) and with no opportunity to increase the
capacity of a closed car body, the diminutive covered hopper cars were removed
from service 2008/2009. As mentioned, the limestone mineral to cement
processing operation continues. The highly specialized LO’s were supplanted by
2,300 cu. ft. Trinity built open top hoppers cars (AAR Class HTS), equipped
with rapid discharge outlet gates. Apparently, the need to keep the minerals
out of the elements and dry was overcome. For a relatively brief period the two
groups of cars were intermixed. Current Google earth images of the Heidelberg Materials
installation show several dozen of the HTS’s cued up for off-loading. Photos of both the Procor built (UNPX/PWCX) and Trinity built
(PWCX) can be found online at https://canadianfreightcargallery.ca/ and https://www.rrpicturearchives.net/
 |
UTCX
44670a1
Built
10/1969 (first car built); renumbered UNPX 121600 |
 |
Bottom UTCX
44670b1
gate
opened |
 |
UTCX
44670c1
Bottom
gate closed |
 |
UTCX
44670c1
Bottom
gate closed |
 |
UTCX
44670e1
Bottom
gate opening fixture |
 |
UTCX
44670f1
Bottom
gate closed |
UTCX
44670g1
Unloading
pit. Note the fixture shown in the top of the photo, I believe employed as a
car shaker to dislodge any frozen minerals
